4GNSS FLYBOX

Simple and compact GNSS receiver for RTK, heading and post-processing

It's designed to collect RAW data with event markers and can be easily integrated into moving platforms, such as UAVs, drones, robots and automotive transport.

Add to cart
    • 4 models
      From budget single frequency to dual antenna receiver
    • Modern navigation module
      4GNSS receivers use latest generation navigation boards
    • Compact and lightweight
      FLYBOX weighs only 35g, which is ideal for integration into UAVs
    • Built-in comparator
      To remove duplicate event marks by setting the silence time
    • Debug Mode
      For testing equipment without a trigger
    • Quality & Reliability
      We have optimized the internal element base and components
    STRONG EVENT TECHNOLOGY
    Our own developments that make GNSS technology easier and more affordable
    Forget about false events when working with external event markers
    The built-in comparator allows you to set the silence time after the event is triggered (0.1 - 1s), when no pulses are processed as event marks.

    So, each photo corresponds to only one event mark, which simplifies the analysis of data for further processing.
    Learn more about our technologies
    4GNSS FLYBOX receivers are available in various modifications.
    Thanks to this, you can easily choose a navigation receiver for your tasks.
    Close
    SKU:
    $
    $
    ADD TO CART
    TECHNICAL SPECIFICATIONS
    • Signal Tracking

      FLYBOX LITE L1
      • 965 channels
      - GPS: L1 C/A
      - BeiDou: B1I
      - GLONASS: L1
      - Galileo: E1
      - SBAS: WAAS, EGNOS, MSAS, GAGAN, SDCM

      FLYBOX LITE
      • 965 channels
      - GPS: L1 C/A, L2C, L2P
      - BeiDou: B1I, B2I/B3I
      - GLONASS: L1, L2
      - Galileo: E1, E5b
      - SBAS: WAAS, EGNOS, MSAS, GAGAN, SDCM

      FLYBOX S
      • 965 channels
      - GPS: L1 C/A, L2C, L2P, L5
      - BeiDou: B1I, B2I, B3I, B1C, B2a, B2b
      - GLONASS: L1 C/A, L1P, L2 C/A, L2P
      - Galileo: E1, E5a, E5b
      - SBAS: WAAS, EGNOS, MSAS, GAGAN, SDCM

      FLYBOX DUAL
      • 1226 channels
      - GPS: L1, L2
      - BeiDou: B1I, B3I
      - GLONASS: L1, L2
      - Galileo: E1, E5b
      - SBAS: WAAS, EGNOS, MSAS, GAGAN, SDCM

    • Positioning

      RTK
      Horizontal: 8 mm + 1 ppm
      Vertical: 15 mm + 1 ppm

      DGPS
      < 0.4 m 3D СКО

      Standalone
      < 1.5 m 3D RMS

      SBAS
      < 1 m 3D RMS

      PostProcessing
      Horizontal: 2.5 mm + 1 ppm
      Vertical: 5 mm + 1 ppm



      Heading

      • Azimuth: (0.2/R)°
      • Roll or Pitch: (0.4/R)°
      R-range between antennas


      Communications

      • 1 micro USB (USB2.0 and higher)
      • 2 Event markers input
      • LITE L1/LITE/S: 1 GNSS antenna MMCX (f)
      • DUAL: 2 GNSS antennas MMCX (f)
      • Data Format

        • Correction data I/O :
        - RTCM 2.X, 3.X
        - CMR (GPS only)
        - CMR+ (GPS only)
        • Position data output:
        - NMEA-0183
        - ComNav Binary
        - Data output rate:
        1 Hz, 2 Hz, 5 Hz, 10 Hz, 20 Hz*



        Physical

        • Size (L × W × H):
        55.8 mm x 44.6 mm x 18 mm
        • Weight: 35 g


        Electrical

        • Input voltage: +5.0 V ~ +17.0 VDC
        • Power consumption: up to 1.3 W
        • Memory: SD-card up to 64GB
